Technical Specification

• For Fabric width from 1600mm to 4200mm and from 01 Chamber to 10 Chamber
• Chamber Size : 10ft (3,048mm), 12ft (3,657mm), 16ft(4,876mm)
• No. of Blowers (7.5 to 12.5 HP) : Two per Chamber(Depending up on the width of Machine)
• Exhaust Motors (3 HP/5 HP) : Nos Depending up on the length of Machine
• Evaporation Capacity : 125 kg of water / ch / hr
• Fabric Width : 1000mm - 4000 in steps of 200mm
• Mech. Speed : 0 - 120 mtr / min 0 - 140
• Over Feed : up tp -5% to +40%
• Heating Media : Oil / Gas / Steam
• Fabric Width : 225 deg celsius
